HDR摄像系统See3CAM_CU20

互补金属氧化物半导体 USB 3.1 全高清

See3CAM_CU20是一个全高清HDR USB摄像头板与超低光性能。它具有在宽温度范围(-40°C至85°C)下无缝流动的能力。这款全高清USB3.1 Gen1 (5Gb/Sec)相机基于1/2.7”AR0230AT CMOS数字图像传感器，像素尺寸为3.0 μm x 3.0 μm，来自on Semiconductor™。它有S-mount (M12)镜头架，允许客户根据自己的要求选择和使用镜头。它是一个即插即用相机(UVC兼容)的Windows, Linux。这款HDR相机还向后兼容USB 2.0主机端口。See3CAM_CU20has a dedicated, high-performance Image Signal Processor chip (ISP) on board, that performs all the Auto functions (Auto White Balance, Auto Exposure control). The ISP and sensor settings have been fine-tuned to generate best-in-class video in uncompressed UYVY. Recently we have launched an enclosure for this camera. This aluminum enclosure ensures safety even in the most challenging conditions. It is FCC and CE compliance camera. Key Features > - Houses e-CAM20_CU0230_MOD - Full HD AR0230AT Color Caméra Module > - Fixed Focus with M12 lens holder > - Electronic Rolling Shutter > - Output format: Uncompressed UYVY format > - Plug-&-Play (UVC compliant - No drivers required) and Backward compatibility with USB 2.0 hosts with limited features and capabilities
